DSX
Featuring all the benefits of our market leading DSX, our 7.5m, 8m & 9m DSX was designed with high-output farmers in mind. It stands alone in the market thanks to its unique combination of row spacings options (16.7cm, 18.7cm, 20cm & 25cm), wide working width and compact EU road legal transport size.
7.5-9m NO-TILL SEED DRILL
Features the market leading DSX no-till disc coulter.
Configurable with either a 7.5m, 8m or 9m working width.
Compact EU road transport size (less than 3m wide and 4m tall).
Choice of 16.7cm, 18.7cm, 20cm and 25cm row spacings.
Optional row cleaners reduce hairpinning.
High capacity 5700L hopper, split 60/40.
Contour following wings.
Uniquely angled undercut disc ensures consistent penetration and closing even in the hardest conditions.
In cab controlled pneumatic closing system.
Parallel linkage for optimum contour following and depth control.
In-house liquid fertiliser solutions.
Various closing wheel options available.
Why choose the Horizon 7.5-9m DSX?
Wide wings, narrow row spacings, high output.
The 7.5-9m DSX is available with a working width of 7.5, 8 or 9 meters. The wings are modular and can be extended, allowing the machine to adapt to your needs as your business grows.
The farmer can also configure row spacings, with options of 16.7cm, 18.7cm, 20cm and 25cm spacings. Thanks to the 7.5-9m DSX’s clamping toolbar, the row unit spacings can easily be adjusted depending on the operators needs.
The 7.5-9m DSX features an innovative design with two folding wings and a fixed center wing. This reduces the size of the machine when folded, meaning that it is EU road legal and can be transported easily without any need for an escort.
This is a feature unique to the Horizon DSX 7.5-9m. No other no-till disc drill on the market combines such narrow row spacings, wide working width and compact EU road legal transport size (less than 3m wide and 4m tall).
Compact EU road legal transport size, fixed center wing.
Multiple seeding configurations.
Sowing all rows
Sowing with double row spacings
Sowing two different products
Contour following wings.
To accommodate for uneven terrain, the 7.5-9m DSX features contour following wings, with the ability to float up to 5 degrees up and down.
Combined with the parallel linkage found on every row unit, the DSX 7.5-9m can deliver planter level accuracy, even in the most challenging conditions.
High capacity hopper, convenient access.
Our 7.5-9m DSX is equipped with a 5700L hopper, split 60/40. The hopper is fully pressurized, with an integrated hydraulic fan.
The 5700L hopper can easily be accessed with our new folding platform. The platform folds with the wing, with a fixed platform and steps to also provide access to our optional GH400.
GH400 - Optional 400l granular hopper.
The GH400 is a compact, modular and highly configurable granular hopper designed for a variety of applications. It can be configured with the 7.5-9m DSX to serve as a small third hopper.
Featuring the DSX metering system, the GH400 is pressurized and capable of distributing a variety of products. Ideal for microgranular fertilizer, slug pellets, Avadex or small seeds.
